| Item No. | Approximate External Dimension (mm) | Approximate Internal Dimension (mm) | Approximate weight (kg) |
| PSC-26.22.10 | 255*215*100(30+70) | 210*170*88(23+65) | 1.1 |
| PSC-28.17.16 | 278*174*162(55+107) | 234*110*150(47+103) | 2.4 |
| PSC-40.28.16 | 400*280*160(60+100) | 340*220*134(40+94) | 2.7 |
| PSC-42.33.17 | 418*328*168(60+108) | 340*216*148(48+100) | 3.5 |
| PSC-45.35.18 | 450*350*180(85+95) | 390*290*150(70+80) | 4 |
| PSC-45.35.21 | 450*350*210(115+95) | 390*290*180(100+80) | 4.1 |
| PSC-45.35.23 | 450*350*230(85+145) | 390*290*200(70+130) | 4.3 |
| PSC-45.35.26 | 450*350*260(115+145) | 390*290*230(100+130) | 4.5 |
| PCS-46.26.17 | 460*260*170(55+115) | 404*194*158(49+109) | 2.6 |
| PSC-48.34.16 | 480*340*162(65+97) | 420*280*140(50+90) | 3.7 |
| PSC-48.34.19 | 480*340*192(65+127) | 420*280*170(50+120) | 4 |
| PSC-49.29.27 | 487*287*270(78+192) | 426*226*230(58+172) | 5.7 |
| PSC-50.25.20 | 500*250*200(60+140) | 430*170*180(45+135) | 3.6 |
| PSC-50.25.23 | 500*250*230(90+140) | 430*170*213(78+135) | 3.9 |
| PSC-50.40.18 | 500*400*180(55+125) | 440*300*135(34+101) | 4.4 |
| PCS-50.42.18 | 504*424*176(73+103) | 450*370*164(66+98) | 4.5 |
| PCS-50.42.20 | 504*424*200(73+127) | 450*370*186(66+120) | 5 |
| PCS-50.42.25 | 504*424*246(73+173) | 450*372*230(66+164) | 5.6 |
| PSC-50.46.23 | 504*460*230(85+145) | 450*406*137(77+60) | 5 |
| PCS-52.36.15 | 515*360*150(50+50+50) | 480*325*120(40+40+40) | 4.7 |
| PSC-53.42.10 | 530*420*100(45+55) | 480*360*78(30+48) | 3.5 |
| PSC-53.42.16 | 530*420*160(45+115) | 480*360*138(30+108) | 4.5 |
| PSC-55.37.17 | 550*366*170(65+105) | 490*306*155(57+98) | 4.6 |
| PSC-55.37.25 | 550*366*250(90+160) | 490*306*220(75+145) | 6 |
| PSC-55.37.32 | 550*366*320(95+225) | 490*306*290(80+210) | 7 |
| PSC-55.40.20 | 550*400*200(70+130) | 482*316*168(55+113) | 5 |
| PSC-57.22.14 | 565*215*135(55+80) | 508*146*115(42+73) | 3.5 |
| PSC-57.41.29 | 574*414*290(50+240) | 518*358*274(42+232) | 6.5 |
| PSC-58.30.26 | 580*300*260(75+185) | 518*220*228(60+168) | 4.7 |
| PCS-60.40.20 | 600*400*200(65+135) | 540*340*185(58+127) | 6 |
| PCS-64.44.27 | 640*440*270(80+190) | 580*380*250(73+177) | 8.5 |
